Audio
Voice codecs:
G.711, G.726
Built-in microphone:Microphone that is found inside the product.
Audio system:System used to play music or speech.
1-way
Camera
Camera shutter speed:Determines the length of time the shutter lets light pass through the lens to the CCD. Shutter speed and aperture together determine exposure.
1/5 - 1 / 32000 s
Tilt angle range:
0 - 80°
Lens viewing angle, diagonal:
134°
Lens viewing angle, vertical:
76°
Lens viewing angle, horizontal:
103°
Design
International Protection (IP) code:The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
IP66
LED indicators:
Power, Status
Mounting type:Type of mounting e.g. wall mounting.
Ceiling/wall
Form factor:The shape or design of the product.
Dome
General
Type:Characteristics of the device.
Unclassified
Image sensor
Progressive scan:Also referred to as noninterlaced scanning, this is a way of displaying, storing, or transmitting moving images in which all the lines of each frame are drawn in sequence. This is in contrast to interlaced video used in traditional analog television systems where only the odd lines, then the even lines of each frame (each image called a video field) are drawn alternately.Progressive scan is used for DVDs and HDTV (high defintion television).
Optical sensor size:Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
25.4 / 2.7 mm (1 / 2.7")
Sensor type:A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
CMOS
Lens system
Fixed focal length:
2.8 mm
Maximum aperture number:
2
Digital zoom:Indicates the digital zoom capacity, the number of times that the picture is enlarged thanks to digital technology.
48x
Zoom capability:The amount that the camera lens can zoom.
Management features
Behavior analysis:
Intrusion detection, Line crossing detection
Web-based management:Using a website/web application to manage something.
Network
Quality of Service (QoS) support:
Number of users:The number of people that use or can use this product.
10 user(s)
Supported network protocols:Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
802.1X, ARP, Bonjour, CIFS / SMB, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTP, PPPoE, QoS (CoS / DSCP), RTSP / RTP / RTCP, SMTP, SNMP, SSL, TCP / IP, TLS 1.2, UDP, UPnP
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.1x, IEEE 802.3af
Ethernet interface type:
Fast Ethernet
Bluetooth:Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
Wi-Fi:Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Networking
Quality of Service (QoS) support:
Number of users:The number of people that use or can use this product.
10 user(s)
Supported network protocols:Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
802.1X, ARP, Bonjour, CIFS / SMB, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTP, PPPoE, QoS (CoS / DSCP), RTSP / RTP / RTCP, SMTP, SNMP, SSL, TCP / IP, TLS 1.2, UDP, UPnP
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.1x, IEEE 802.3af
Ethernet interface type:
Fast Ethernet
Bluetooth:Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
Wi-Fi:Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Night vision
Number of illumination LEDs:
4
Night vision distance:
30 m
Night vision:Night vision is technology which allows you to see in low light conditions.
Operational conditions
Operating relative humidity (H-H):
0 - 98%
Operating temperature (T-T):The minimum and maximum temperatures at which the product can be safely operated.
-30 - 50 °C
Packaging content
Number of cameras:The quantity of cameras that product can support.
1
Performance
Certification:
EMC: CE (EN55032, EN55024 Class A, EN50121-4 ), FCC (FCC Part 15 Subpart B Class A),
RCM (AS/NZS CISPR32 Class A), VCCI (VCCI-CISPR 32 Class A);
Saf ety : UL (UL62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471);
Env ironment: IK10 (IEC 62262), IP66 (IEC 60529);
IA: BIS (IS 13252), BSMI (EMC: CNS 13438, Saf ety : CNS 14336-1)
Infrared (IR) cut-off filter:
Wide Dynamic Range (WDR):
Connectivity technology:
Wired
Placement supported:Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
Outdoor
Type:Characteristics of the device.
IP security camera
Ports & interfaces
Ethernet LAN (RJ-45) ports:Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
1
Power
Power consumption (max):The maximum amount of power used by the device.
8.55 W
Power consumption (typical):Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
6.15 W
Power source type:What the power source is.
PoE
Security
Alert notification type:
E-mail
Intelligent Video Surveillance (IVS) system features:
Abandoned object, Face detection, Missing object
Password protection:The computer, smartphone etc. can only be used when the correct password is entered, therefore making it more secure.
Storage
Internal memory:The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
1000 MB
Maximum memory card size:The maximum size of memory card that can be used with this device.
1 TB
Compatible memory cards:Types of memory cards which can be used with this product.
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Card reader integrated:The device includes a card reader e.g. a card reader in the disk bay of a computer or thin client to permit log-on using smart/pin cards.
System requirements
Mac operating systems supported:Mac operating systems e.g. OS X can be used with the device.
Mac OS X 10.12 Sierra
Windows operating systems supported:Windows vesions wich can be used with the device.
Windows 10, Windows 7, Windows 8
Video
Back Light Compensation (BLC):
Digital Wide Dynamic Range (DWDR):
Highlight Compensation (HLC):
Image quality adjustment:
Brightness, Contrast, Saturation, Sharpness
Noise reduction technology:
3D noise reduction
Supported graphics resolutions:The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
1920 x 1080 (HD 1080), 2560 x 1920
Video compression formats:
H.264, H.265, M-JPEG
Video formats supported:The type of video formats that can be used by this device.
H.264, H.265, M-JPEG
Total megapixels:A megapixel (MP or Mpx) is one million pixels, and is a term used not only for the number of pixels in an image, but also to express the number of image sensor elements of digital cameras or the number of display elements of digital displays. For example, a camera that makes a 2048 × 1536 pixel image typically uses a few extra rows and columns of sensor elements and is commonly said to have "3.2 megapixels" or "3.4 megapixels", depending on whether the number reported is the "effective" or the "total" pixel count (as opposed to the 2048 × 1536 = 3,145,728 finished image pixels).
5 MP
Maximum resolution:The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
2560 x 1920 pixels
Weight & dimensions
Weight:Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
605 g
Diameter:Distance from one side of a body (circle or sphere) to the other side, measured by a straight line passing through the centre of the body.
12.9 cm
Height:The measurement of the product from head to foot or from base to top.
94 mm
