Design
Cable lock slot:Holes on the edge of devices through which a cable lock can be passed, so the device can be locked to a desk etc.
Cable lock slot type:
Kensington
Market positioning:
Portable
Display
Built-in display:A display which is part of the product, so you do not need to attach another display.
Features
Number of OSD languages:
30
Preset modes:
3D, Bright, Custom, Infographic, Presentation, Spreadsheet, sRGB
Noise level (economic mode):
29 dB
Noise level:The amplitude level of the undesired background noise, usually measured in decibels (db).
34 dB
General
Type:Characteristics of the device.
Unclassified
Lens system
Zoom ratio:Measures how much the camera can adjust its focus for distance shots. A 3x zoom ratio changes the camera's focal length by a factor of three, from 35 mm to 105 mm for example.
1.1:1
Aperture range (F-F):Aperture range of the device's optics, expressed in f-stops.
2.56 - 2.68
Focal length range:
22 - 24.1 mm
Light source
Service life of light source (economic mode):
10000 h
Service life of light source:
6000 h
Multimedia
Number of built-in speakers:
1
RMS rated power:RMS (Root mean square) is a measure of the continuous power required by a device, in particular audio amplfiers and loudspeakers.
10 W
Built-in speaker(s):The device contains speaker(s) to produce sound.
Network
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Networking
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Operational conditions
Operating temperature (T-T):The minimum and maximum temperatures at which the product can be safely operated.
0 - 40 °C
Packaging content
Cables included:
Power, VGA
Ports & interfaces
PC in (D-Sub):The socket (port) to receive input from a PC via a D-sub, which is a connector with a characteristic D-shaped metal shield.
Serial interface type:
RS-232
Microphone in:The socket where a microphone is connected to the device.
Headphone outputs:Number of sockets /ports where headphones are connected.
1
USB 2.0 Type-A ports quantity:
1
USB 2.0 ports quantity:Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
1
S-Video inputs quantity:The number of ports (input sockets) for S-Video, which is a signalling standard for standard definition video, typically 480i or 576i.
1
Composite video in:The socket (port) for the composite video input (white cable).
1
DVI port:Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor.
HDMI ports quantity:The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
2
VGA (D-Sub) ports quantity:Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM.
1
Power
AC input frequency:
50/60 Hz
AC input voltage:The voltage of the AC electricity that is inpitted into the product.
100 - 240 V
Power consumption (economy mode):
215 W
Power consumption (max):The maximum amount of power used by the device.
280 W
Power consumption (standby):The amount of electricity that is consumed when the product is on standby.
0.5 W
Power consumption (typical):Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
260 W
Power source:What is providing power for the product e.g. mains electricity.
AC
Projector
Keystone correction, vertical:
-40 - 40°
Horizontal scan range:
15 - 102 kHz
Vertical scan range:
23 - 120 Hz
Number of colours:Maximum number of viewable colors.
1.07 billion colours
Screen size compatibility:The different screen sizes which the device can work with.
1524 - 3810 mm (60 - 150")
Native aspect ratio:The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.
4:3
Contrast ratio (typical):The difference in light intensity between the brightest white and the darkest black.
20000:1
Projector native resolution:
SVGA (800x600)
Projection technology:
DLP
Projector brightness:
4000 ANSI lumens
Video
Supported graphics resolutions:The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
640 x 480 (VGA), 1920 x 1200 (WUXGA)
3D:The device can be used with 3D technology.
Analog signal format system:The supported protocols for exchanging analog signals.
NTSC, PAL, SECAM
Weight & dimensions
Height:The measurement of the product from head to foot or from base to top.
120 mm
Depth:The distance from the front to the back of something.
221 mm
Width:The measurement or extent of something from side to side.
296 mm
Weight:Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
2.3 kg
